21
Setting ATW-T3201 / ATW-T3201a / ATW-T3202 / ATW-T3202a
Adjusting the gain
1. From the menu screen, press the UP/DOWN button to select
[GAIN], and then press the SET button.
0dB
GAIN
2. Press the UP/DOWN button to select the gain you wish to set.
• The level changes 2dB +/- each time you press the UP/DOWN button.
• It can be set from -10 to +20 dB.
3. Press the SET button.
• The setting is complete.
Setting the RF power
1. From the menu screen, press the UP/DOWN button to select
[RF POWER], and then press the SET button.
2. Press the UP/DOWN button and select [High:30mW],
[Low:10mW] or [Off].
3. Press the SET button.
• The setting is complete.
Setting HPF (High-Pass Filter)
1. From the menu screen, press the UP/DOWN button to select
[HPF], and then press the SET button.
2. Press the UP/DOWN button to select [On] or [Off].
3. Press the SET button.
• The setting is complete.
Setting lock
1. From the menu screen, press the UP/DOWN button to select
[LOCK], and then press the SET button.
Unlock
LOCK
2. Press the UP/DOWN button to select [Lock] or [Unlock].
Lock Locks transmitter buttons
Unlock Unlocks transmitter buttons
3. Press the SET button.
• The setting is complete.
Setting the function for the function button
Select the function to be performed when the function button is
pressed.
1. From the menu screen, press the UP/DOWN button to select [Fn
BUTTON], and then press the SET button.
2. Press the UP/DOWN button to select the function you wish to set.
Disable No function
PushToMute
(only for ATW-T3201 /
ATW-T3201a)*
1
*
2
Mutes while pressed (even when transmitter
buttons are locked
PushToTalk
(only for ATW-T3201 /
ATW-T3201a)*
1
*
2
Speaking into the microphone is available
while pressed (even when transmitter buttons
are locked)
Mute
(only for ATW-T3202
/ ATW-T3202a)
Presses and hold to mute the transmitter ON/OFF
MuteOnLock
(only for ATW-T3202
/ ATW-T3202a)
Presses and hold to mute the transmitter ON/
OFF (even when transmitter buttons are locked)
QuickMute
(only for ATW-T3202 /
ATW-T3202a)*
2
Presses to mute the transmitter ON/OFF
Bkup Freq Presses and hold to switch to backup
frequency (When selected, set the frequency,
group, and channel.)
RF Off Presses and hold to turn on/off RF power
*1 When this function is selected, the function of the MUTE switch set in mute mode is not
available.
*2 When this function is selected, turning the screen back on if it shuts off cannot be used.
3. Press the SET button.
• The setting is complete.
High:30mW
RF POWER
O
HPF
Disable
Fn BUTTON
To Next Page
