Audio Technica ATW-T3201a - Part Names and Functions; ATW-R3210 Receiver Front Panel

4
Part names and functions
ATW-R3210
Front panel
❶ Power button ( )
Use to turn the receiver on or off.
❷ IR sync window
Use to IR SYNC with the transmitter (ATW-T3201, ATW-T3201a, ATW-T3202, ATW-T3202a).
❸ Display
Displays the receiver state and setting menus.
❹ BACK button
Press to take the display back one screen.
Returns to the Main screen when pressed and held.
❺ Control dial
Switches the screen when you turn the dial.
Displays the setting menu when you press the dial. Turn the dial to select a setting and press to confirm.
When you press and hold the dial, QUICK SYNC is started.
❷❶ ❹ ❺❸
