Physical and Electrical Characteristics
Analogue Input 1
Connector Balanced, via female 3-pin XLR on front panel
Phantom power 48 V phantom power switch
AIR function Front panel switch or via Focusrite Control
Analogue Input 2
Connector
¼” (6.35 mm) jack socket on front panel
INST mode: unbalanced, 2-pole (TS)
LINE mode: balanced (TRS)
Line/Instrument switching Front panel switch or via Focusrite Control
Analogue Outputs
Main outputs Balanced, 2 x ¼” TRS jacks on rear panel
Stereo headphone output ¼” TRS jack on front panel
Output level control
(main and headphone)
On front panel
Direct Monitoring Front panel switch; allows zero-latency monitoring of inputs
Other I/O
USB 1 x USB 2.0 Type C connector
Front Panel Indicators
USB power Green LED
Gain Halos Tri-colour LED rings (concentric with GAIN controls)
Phantom power Red LED
Instrument mode Red LED
AIR mode Amber LED
Direct Monitor mode Green LED
Weight and Dimensions
W x H x D
143.5 mm x 43.5 mm x 95.8 mm
5.65 in x 1.71 in x 3.77 in
Weight
320 g
0.71 lb
