CHAPTER3 Physical Description

Mediant 800 Gateway & E-SBC | Hardware Installation Manual

Item # Label Description

Note: This port is available only if the device is equipped with the

OSN server (customer ordered).

3 - Reset button for resetting the OSN server.

4 GE 1

GE 2

10/100/1000Base-T Ethernet ports (RJ-45) for connecting directly to

the OSN server. For example, one port can be connected to the LAN

(to IP Phones) and the second port to the WAN interface (to an IP

PBX).

Note: The number of ports depends on ordered OSN server platform

(see Connecting the OSN Server on page26).

5 Protective earthing screw.

6 Mediant

800B: 100-

240V~4A

50-60Hz

Mediant

800C: 100-

240V~1.5A

50-60Hz

3-Prong AC power supply entry.

7 DC IN 12V-

10A

DC power inlet for accepting a DC terminal block plug.

Note:

■ DC power is applicable only to Mediant 800C.

■ Use only the AC/DC power adaptor that is supplied by

AudioCodes to connect the DC inlet.

- 9 -
