AudioCodes Mediant MSBR Series Troubleshooting

Configuration Note 10 Document #: LTRT-40386
Troubleshooting the MSBR
Source Description
eth-lan vlan4001
only
Defines internal link between Data and Voice-CPUs only.
eth-lan all-int-
voip
Defines all internals links between Data and Voice-CPUs, and LAN
Ethernet interfaces.
eth-lan all-int-
voip only
Defines all internals links between Data and Voice-CPUs only.
wifi-lan
Defines the Wi-Fi interface.
2.1.1 Changing the Debug File Destination Target
The target must be set prior to running the start command. The following commands set the
debug file destination target:
Table 2-3: Debug File Destination Target Commands
Source Description
debug capture data
physical target tftp
Sends the capture to the TFTP server.
debug capture data
physical target usb
Saves the capture to USB storage.
debug capture data
physical target ftp
Uses an FTP server (specify username and password).
Note: If you are using the USB as a target destination, the USB storage must be plugged
in to the MSBR.
While the target destination is the USB, the debug capture file size is limited to the USB
storage capacity. The 20MB limitation is for TFTP and FTP target files. Using the USB
as a debug capture target causes degradation in MSBR performance and should be
used only for debugging purposes.
2.1.2 Viewing Currently Configured Capture
Use the following command to view the currently configured capture.
Table 2-4: Viewing Currently Configured Capture Command
Source Description
debug capture data
physical show
Displays currently configured capture.
