6.3 Providing AT Modem Command Responses
AudioCodes provides the capability for recording AT modem commands between the
USB device and the AudioCodes router. This capability allow us to analyze the 3G device in
case of unsupported devices.
debug usb-3g serial-trace cli
Start serial trace]
TX 87
-- 0000: 7e ff 03 00 21 45 00 00 4f 00 00 40 00 40 11 80 |....!E..O..@.@..|
-- 0010: a5 b0 0c 85 74 c3 bd c0 ba 00 a1 c8 c9 00 3b fc |....t.........;.|
-- 0020: 56 30 31 02 01 01 04 06 70 75 62 6c 69 63 a2 24 |V01.....public.$|
-- 0030: 02 03 04 1d 0f 02 01 00 02 01 00 30 17 30 15 06 |...........0.0..|
-- 0040: 11 2b 06 01 04 01 a7 0b 09 0a 0a 02 0c 01 01 0d |.+..............|
-- 0050: 01 00 81 00 88 d3 7e |....... |
RX 119
-- 0000: 7e ff 7d 23 7d 20 21 45 7d 28 7d 20 46 7d 21 6a |...#. !E.(. F.!j|
-- 0010: 7d 20 7d 20 74 7d 31 8b 3c c3 bd c0 ba b0 7d 2c |. . t.1.<......,|
-- 0020: 85 74 c8 ca 7d 20 a1 7d 20 32 23 d7 30 28 7d 22 |.t... .. 2#.0(."|
-- 0030: 7d 21 7d 21 7d 24 7d 26 70 75 62 6c 69 63 a0 7d |.!.!.$.&public..|
-- 0040: 3b 7d 22 7d 23 7d 24 7d 3d 7d 30 7d 22 7d 21 7d |;.".#.$.=.0.".!.|
-- 0050: 20 7d 22 7d 21 7d 20 30 7d 2e 30 7d 2c 7d 26 7d | .".!. 0..0.,.&.|
-- 0060: 28 2b 7d 26 7d 21 7d 22 7d 21 7d 21 7d 23 7d 20 |(+.&.!.".!.!.#. |
-- 0070: 7d 25 7d 20 2b b5 7e |.%. +.. |
TX 81
-- 0000: 7e ff 03 00 21 45 00 00 49 00 00 40 00 40 11 80 |....!E..I..@.@..|
-- 0010: ab b0 0c 85 74 c3 bd c0 ba 00 a1 c8 ca 00 35 e0 |....t.........5.|
-- 0020: ba 30 2b 02 01 01 04 06 70 75 62 6c 69 63 a2 1e |.0+.....public..|
-- 0030: 02 03 04 1d 10 02 01 00 02 01 00 30 11 30 0f 06 |...........0.0..|
-- 0040: 08 2b 06 01 02 01 01 03 00 43 03 77 07 8b 9a bf |.+.......C.w....|
-- 0050: 7e |. |
RX 136
-- 0000: 7e ff 7d 23 7d 20 21 45 7d 28 7d 20 4f 7d 21 6b |...#. !E.(. O.!k|
-- 0010: 7d 20 7d 20 74 7d 31 8b 32 c3 bd c0 ba b0 7d 2c |. . t.1.2......,|
-- 0020: 85 74 c8 cb 7d 20 a1 7d 20 3b 7d 20 d1 30 31 7d |.t... .. ;. .01.|
-- 0030: 22 7d 21 7d 21 7d 24 7d 26 70 75 62 6c 69 63 a0 |".!.!.$.&public.|
-- 0040: 24 7d 22 7d 23 7d 24 7d 3d 7d 31 7d 22 7d 21 7d |$.".#.$.=.1.".!.|
-- 0050: 20 7d 22 7d 21 7d 20 30 7d 37 30 7d 35 7d 26 7d | .".!. 0.70.5.&.|
-- 0060: 31 2b 7d 26 7d 21 7d 24 7d 21 a7 7d 2b 7d 29 7d |1+.&.!.$.!..+.).|
-- 0070: 2a 7d 2a 7d 22 7d 2c 7d 21 7d 21 7d 29 7d 21 7d |*.*.".,.!.!.).!.|
-- 0080: 20 7d 25 7d 20 38 e2 7e | .%. 8.. |
TX 87
-- 0000: 7e ff 03 00 21 45 00 00 4f 00 00 40 00 40 11 80 |....!E..O..@.@..|
-- 0010: a5 b0 0c 85 74 c3 bd c0 ba 00 a1 c8 cb 00 3b 00 |....t.........;.|
-- 0020: 53 30 31 02 01 01 04 06 70 75 62 6c 69 63 a2 24 |S01.....public.$|
-- 0030: 02 03 04 1d 11 02 01 00 02 01 00 30 17 30 15 06 |...........0.0..|
-- 0040: 11 2b 06 01 04 01 a7 0b 09 0a 0a 02 0c 01 01 09 |.+..............|
-- 0050: 01 00 81 00 c8 fa 7e |....... |
