AudioCodes Mediant User Manual

Configuration Note 9. Pseudo Wires
Version 6.8 31 Mediant MSBR
MSBR1(conf-mep)# link-state reflect
MSBR1(conf-mep)# vlan 1
MSBR1(conf-mep)# interface GigabitEthernet 0/0
MSBR1(conf-mep)# continuity-check interval 1s
MSBR1(conf-mep)# exit
MSBR1(conf-if-VLAN 1)# interface VLAN 1
MSBR1(conf-if-VLAN 1)# link-state monitor
MSBR1(conf-if-VLAN 1)# no shutdown
MSBR1(conf-if-VLAN 1)# exit

MSBR2:
MSBR2(config-data)# ethernet cfm aging-time 0
MSBR2(config-data)# ethernet cfm debounce 5
MSBR2(config-data)# ethernet cfm mep domain TEST mpid 10
MSBR2(conf-mep)# level 6
MSBR2(conf-mep)# domain-name-format none
MSBR2(conf-mep)# service number 1
MSBR2(conf-mep)# link-state reflect
MSBR2(conf-mep)# vlan 1
MSBR2(conf-mep)# interface GigabitEthernet 0/0
MSBR2(conf-mep)# continuity-check interval 1s
MSBR2(conf-mep)# exit
MSBR2(conf-if-VLAN 1)# interface VLAN 1
MSBR2(conf-if-VLAN 1)# link-state monitor
MSBR2(conf-if-VLAN 1)# no shutdown
MSBR2(conf-if-VLAN 1)# exit
The following show command shows the MEP status:
MSBR# show data ethernet cfm
Local MEPs:
MPID VLAN RmtRDI MAC Remote XCON
----------------------------------------
10 OK OK OK OK OK
Remote MEPs:
MPID Stat DomainName MAC Age Intf Port
-----------------------------------------------------------------
10 UP TEST 00:90:8f:4a:23:44 0s Up Up
#show command after disconnect cable:
Local MEPs:
MPID VLAN RmtRDI MAC Remote XCON
----------------------------------------
10 OK OK OK Error OK
Remote MEPs:
MPID Stat DomainName MAC Age Intf Port
-----------------------------------------------------------------
