AudioCodes MediaPack MP-124 Installation Manual

Version 6.0 11 March 2010
Installation Manual 1. Introduction
1 Introduction
This manual provides you with step-by-step procedures for initial and basic setup of the
device, including hardware installation and software configuration. The flowchart below
summarizes these steps:
Figure 1-1: Required Steps to Install the Device
Notes:
• For detailed information on how to fully configure the device, refer to the
device's User’s Manual
• Prior knowledge of IP networking is recommended.
.

AudioCodes MediaPack MP-124 Specifications

General

Model	MediaPack MP-124
Category	Gateway
Protocols	SIP, H.323, MGCP
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Fax Support	T.38
Management	SNMP
Security	TLS/SRTP
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25 to 70°C
Humidity	10% to 90%, non-condensing
Analog Ports	24 FXS
