AudioCodes MediaPack MP-124 Installation Manual

Version 6.0 31 March 2010
Installation Manual 2. Installing the Device
4. Insert and fasten the male connector to the female 50-pin Telco connector on the
MP-124 rear panel (labeled Analog FXS Lines 1-24
5. Connect the telephone lines from the MDF adaptor block to a fax machine, modem, or
telephones by inserting each RJ-11 connector on the 2-wire line cords of the POTS
phones into the RJ-11 sockets on the front of an MDF adaptor block, as shown in the
figure below.
).
Figure 2-21: MP-124 in a 19-inch Rack with MDF Adaptor

AudioCodes MediaPack MP-124 Specifications

General

Model	MediaPack MP-124
Category	Gateway
Protocols	SIP, H.323, MGCP
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Fax Support	T.38
Management	SNMP
Security	TLS/SRTP
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25 to 70°C
Humidity	10% to 90%, non-condensing
Analog Ports	24 FXS
