Audiolab 8200P Service Manual

ASSEMBLY PARTS LIST
13
8200P
8200P-Assembly Bom-P1/2
R/N P/N PART NAME DESCRIPTION QTY
1 300-1032410000R Front Panel finish and anodized aluminium 1
2
215-1027410001R Button Cap painted 1
3
215-1027410000R Power Button painted 1
4
305-1027410002R
Mains Switch
Bracket
painted
1
5 500-3050240300AR Nut M3 Ni 11
6 263-0020100102R EVA 20*10*10mm EVA 1
7 309-1032410000R Chassis painted and silkscreen 1
8 588-3000066037R Screw M3*6 25
9 226-0230191911R Foot black 4
10 319-1027410001R Side Panel sand blast and anodized 2
11 307-1050800081R Nut gold plated 4
12 331-1031410001R
PCB Terminal
Connector
gold plated
4
13 331-1031410000R Terminal Connector gold plated 4
14
537-3002000306R Screw M3*10 2
15 513-6412150780R Washer Φ6.4XΦ12X1.5 NI 1
16 500-6000000300R Nut M6 1
17 302-1032410000R Top Cover
sand blast and anodized
aluminium 1
18 534-3002061006R Screw M3*6 18
19 534-3002100606R Screw M3*10 11
20 306-1003770012R
Main
Radiator(Machning
ed)
anodized
1
21 306-1003770013R Main Radiator anodized 1
22 306-1003770001QR Radiator(1) anodized 1
23 306-1003770002QR Radiator(2) anodized 2
24 306-1003770003QR Radiator(3) anodized 4
25 308-1031410000R
Transformer
Insulation Board
black painted
1
26 231-2136000102R Rubber Washer Φ136*Φ10*1 2
27 348-1300300230R Copper Post nickel plated 2
28 231-2013005012R PVC Washer Φ12.5*Φ4.5*0.1mm 2
29 588-3000106037R Screw M3*10 1
30 223-0700220311R Insulation Post φ7.5*3.1mm,NYLON66(UL) 1
