SPECIFICATION
2
8200P
Rated Output Power 100W (20dBW) /Channel into 8 both channels drive
Inputs Sensitivity 1V rms for 100W into 8
Input Impedance: 50k
Load Connected in parallel with INPUT
Gain 29.0 dB at1kHz
Signal To Noise Ratio(IHF, rel. 0.dBW)Better than 95 dB
Frequency Response 20 Hz-20 kHz ±0.3 dB
0.1Hz-75 kHz -3 dB.
Total Harmonic Distortion&Noise Less than 0.05%
Channel Balance Within1dB
Polarity (Phase) Non-Inverting
Muting Muting controlled automatically
Operating Temperature Range 10-35 °C
Power Requirements(Depending on
Region)
50-60Hz 100V, 110-120V, and 220-230V models
available
Maximum Power Consumption:500 VA
Dimensions (W×H×D) 444×78×326mm
Weight Net: 8.4 kg Shipping: 9.8 kg
