Audiolab 8200P Service Manual

ELECTRONIC PARTS LIST
15
8200P
8200P-Electronic Bom-P1/5
R/N P/N PART NAME DISCRIPTION QTY LOCATION
1 046-9400000400R 909 Terminal red/black 4
2 062-5118000201R Mains Cable 2 meter American 1
3 041-1376000000QR Mains Switch
SWITCH MAINS２P
SDDSA 3289A
1
4 071-1100000000R Tie Wrap 100MM YJ-100 20
5 044-1700000000QR Mains Inlet
MAINS INLET 2 POLE 2
FUSE LOCS
1
6 742-3501000000R Heat Sink Φ35 black 0.1
7 060-4180310312R
Double Insulated
Wire
UL1672 18 AWG blue
L=310MM
1
8 060-4180310112R
Double Insulated
Wire
UL1672 18AWG brown
L=310MM
1
9 053-1020410152R
Mains Switch
PCB
single layer PCB
MAINS SWITCH 200
SERIES
1
10 022-2000022348R Transformer
115V 50/60HZ Noratel
TI-103410 500AV D=139
Iss 1 SW/120ºC
1
11 031-2200813121HR Fuse Tube
T5A/250V 213 5*20MM
LITTELFUSE
2
12 008-1003025005R Cap MKT 10NF/250V 10% 2
13 053-1374001104QR
Mains Switch
PCB
PCB MAINS SWITCH
200 SERIES
1
14 019-0011022000QR LED LED RED 1
15 742-0301000000R Heat Sink Φ3 /BLK 0.2
16 742-1001000000R Heat Sink Φ10 / BLK 0.2
17 742-0501000000R Heat Sink Φ5/ BLK 0.05
18 742-1001000000R Heat Sink Φ10/ BLK 0.2
19 055-0302029333R Flat Wire
2P L=290MM UL1007
24#
1
20 088-1032410000R
8200P AMP
(Stereo)
8200P PCBA 1
21 053-103241A000R
8200P AMP
ISS5
single layer FR-4 KB
20Z blue /osp
414.5*162*1.6MM
1
22 001-6801205010QR Resistor 680R 1/4W 1% 12
R106.107.117.118.131.132
.206.207.217.218.231.232
23 001-2202205010QR Resistor 2K2 1/4W 1% 2 R116.226
24 001-5601205010QR Resistor 560R 1/4W 1% 9
R125.126.159.160.225.226
.259.260.311
25 001-3301205010QR Resistor 330R 1/4W 1% 2 R141.241
26 001-2203205010QR Resistor 22K 1/4W 1% 8
R137.138.152.153.237.238
.252.253
