Audiolab 8200P Service Manual

ELECTRONIC PARTS LIST
16
8200P
8200P-Electronic Bom-P2/5
R/N P/N PART NAME DISCRIPTION QTY LOCATION
27 001-1000205010QR Resistor 10R 1/4W 1% 4 R135.136.235.236
28 001-1803205010QR Resistor 18K 1/4W 1% 2 R108.208
29 001-1802205010QR Resistor 1K8 1/4W 1% 4 R150.151.250.251
30 001-1004205010QR Resistor 100K 1/4W 1% 5 R102.161.202.261.304
31 001-1005205010QR Resistor 1M 1/4W 1% 1 R314
32 001-1504205010QR Resistor 150K 1/4W 1% 2 R307.315
33 001-6803205010QR Resistor 68K 1/4W 1% 1 R317
34 001-1003205010QR Resistor 10K 1/4W 1% 3 R303.305.319
35 001-3304205010QR Resistor 330K 1/4W 1% 1 R320
36 001-5603205010QR Resistor 56K 1/4W 1% 1 R313
37 001-1001205010QR Resistor 100R 1/4W 1% 4 R129.130.229.230
38 001-4700205010QR Resistor 47R 1/4W 1% 4 R165.166.265.266
39 001-3302205010QR Resistor 3K3 1/4W 1% 1 R306
40 001-3902205010QR Resistor 3K9 1/4W 1% 6 R113.127.128.213.227.228
41 001-4703205010QR Resistor 47K 1/4W 1% 6 R139.140.239.240.312.318
42 001-8204205010QR Resistor 820K 1/4W 1% 2 R105.205
43 001-6802205010QR Resistor 6K8 1/4W 1% 1 R310
44 001-5600205010QR Resistor 56R 1/4W 1% 8
R144.145.109.209.244.245
.157.257
45 001-4701205010QR Resistor 470R 1/4W 1% 10
R110.111.154-
156.210.211.254-256
46 001-1801205010QR Resistor 180R 1/4W 1% 2 R158.258
47 001-1002205010QR Resistor 1K 1/4W 1% 6 R112.119.120.212.219.220
48 001-1002205014QR Resistor 1K 1/4W 1% 1 R309
49 001-2209205010QR Resistor 2R2 1/4W 1% 1 R316
50 001-2200205010QR Resistor 22R 1/4W 1% 4 R142.143.242.243
51 001-0470308050R Resistor 4.7Ω 2W J 4 R149.249.321.322
52 001-0000105050QR Resistor 0R 1/4W 5% 32 WL1-28.33-36
53 001-1101405010QR Resistor 110R 1/4W 1% 2 R115.215
54 001-3301409010QR Resistor 330R 1W 1% 2 R401.402
55 001-4701405010QR Resistor 470R 1/4W 1% 2 R122.221
56 001-1102405010QR Resistor 1k1 1/4W 1% 2 R162.262
57 001-3902405010QR Resistor 3k9 1/4W 1% 2 R104.204
58 001-1503405010QR Resistor 15k 1/4W 1% 2 R114.214
59 001-4703405010QR Resistor 47k 1/4W 1% 2 R103.203
60 001-8204405010QR Resistor 820k 1/4W 1% 2 R101.201
61 001-1502109050QR Cap 1K5 3W 5% 4 R123.124.223.224
62 016-1041110001HR Cap
0.1UF/100V 10% MKS4
10PCM WIMA WIMA
8
C110-
112.115.210.211.212.215
63 016-1021132201QR Cap
FKP2 1000PF/100V
2.5% WIMA PCM5
4 C108.109.208.209
64 016-4710832201R Electrolytic Cap 470pF 63V 2.5% 2 C103.203
65 006-4794051173HR Electrolytic Cap
ELNA 4U7 20% 63V
RE3-63V4.7ME3
5*11mm
4 C113.114.213.214
