ELECTRONIC PARTS LIST
17
8200P
8200P-Electronic Bom-P3/5
R/N P/N PART NAME DISCRIPTION QTY LOCATION
66 006-1036508073QR Cap
10000U/63V +50/-20%
Φ35*80
4PCB
67 013-2250120505QR Cap
2U2 10% 50V MSK2
WIMA
4 C121.122.221.222
68 008-4703002517QR Transistor
0U047 +80/-20% 25V
5YF
2 C118.220
69 018-3200653115R Transistor ZTX653 TO-92 3 Q115.215.304
70 018-3200753115R Transistor ZTX753 TO-92 3 Q116.216.306
71 018-0101477113QR Transistor
2SA1477 PNP TO-
126ML SANYO
2 Q113.213
72 018-0303787113QR Transistor
2SC3787 NPN TP-
126ML SANYO
2 Q114.214
73 018-0101668111QR Transistor
TRAN 2SA1668 PNP
TO-220F SANKEN
2 Q120.220
74 018-0304382111QR Transistor
2SC4382 NPN TO-220F
SANKEN
2 Q119.219
75 018-2700042115QR Transistor
TRAN ZTX457 NPN TO-
92
6 Q117.125.127.217.225.227
76 018-2700092115QR Transistor
TRAN ZTX757 PNP E-
Line
6 Q118.126.128.218.226.228
77 018-0302922110QR Transistor
TRAN 2SC2922 NPN
MT-200 SANKEN
4 Q123.124.223.224
78 018-0101216110QR Zener Diode
TRAN 2SA1216 PNP
MT-200 SANKEN
4 Q121.122.221.222
79 067-3300086000QR Diode
DIODE BZV86-2V0
STABLSTOR
4 D112.113.212.213
80 067-1104148000R Diode IN4148 33
D214-217.220.221.301-
303.305-309.311
D101.102.106~109.114~11
7.
81 067-2204002000R Zener Diode IN4002 4 D110.111.210.211
82 067-3379479000QR Zener Diode
DIODE BZX79C 4V7
ZENER
2 D103.203
83 067-3307912000QR Zener Diode
DIODE BZX79C 12V
ZENER
5 D104.105.204.205.310
84 067-3379629000QR Inductor
DIODE BZX79C 6V2
ZENER
5 D118.119.218.219.304
85 080-0315000010QR IC 1.5UH 2 L301.302
86 017-4570000000QR Socket OPA134PA DIP08 BB 2 IC101.201
87 051-1004114034QR Tie Wrap 4W T5857-AABE 1 J401
88 071-2480000000QR Resistor YJ-330 2
89 001-3303205010R Resistor 33K 1/4W F 1 R301
90 001-2002205010QR Cap 2K 1/4W 1% 4 R133.134.233.234
91 836-4700012505QR Cap
47P 10% 125V
POLYSTYRENE
2 C401.402
