ELECTRONIC PARTS LIST
R/N P/N PART NAME DISCRIPTION QTY LOCATION
92 013-1010310507R Potentiometer 100pF 100V 5% 4 C106.107.206.207
93 020-5022121317R Insulation
5K 25% BOURNS
3329H-1-502LF
2 RV101.201
94 324-0380250101QR Effect Transistor 38*25MM 8
Q121.122.221.222,Q123.1
24.223.224
95 018-0500369115R 12 AWG WIRE
2SK369GR TO-92
TOSHIBA ("matched
pairs")
4 Q101.Q201
96 060-4181450012QR 12 AWG WIRE red L=145MM 1
97 060-4181840412QR 12 AWG WIRE black L=184MM 2
98 060-4181740512QR 12 AWG WIRE white L=174MM 1
99 060-4181740012QR 12 AWG WIRE red L=174MM 1
100 060-4181450512QR 12 AWG WIRE white L=145MM 1
101 060-4181210012QR 12 AWG WIRE red L=121MM 2
102 001-4702205010QR Resistor 4K7 1/4W 1% 3 R134.234.308
103 009-1031008110QR Cap 10NF/100V 20% 3 IC PIN4&7
104 060-0120240412R WIRE 12# BLK L=237MM 2
105 016-3320800001R Cap
3300P 5% 63V FKP2
WIMA PH5MM
4 C104.123,204,223
106 024-2030071054HR Relay
JW1FSN-DC24V
AJW4212 NAIS
2 RY301.302
107 016-4740810001R Cap
0U47 10% 63V MKS2
WIMA PH5MM
1C306
108 016-1041300001R Cap
0.10uf 250v 5%
PH=10MM WIMA
1C305
109 016-3331100001R Cap
0U033 5% 100V MKS2
WIMA PH5MM
4 C116.117.216.217
110 016-1041100001R Cap
0U1 5% 100V MKS2
wima ph5mm
5 C101,102,201,202,307
111 006-2204051153HR Electrolytic Cap
ELNA 22U 20% 35V
RE3-35V220ME3
5*11mm
4 C119,120,218,219
112 006-4704051133HR Electrolytic Cap
ELNA 47U 20% 16V
RE3-16V470ME3
5*11mm
2 C105,205
113 006-1014162552QR Electrolytic Cap
ELNA RE3-35V-101M
F3 100UF 35V
3 C308,309,310
114 056-4102220000R Conector JS-1001-02 1 J1
115 086-0400000000R Conector GND PC205 2
116 071-1100000000R Tie Wrap 100MM YJ-100 12
117 331-1031410001R
Connector Socket
B
gilding 4 WL29.30.31.32
118 306-1003770013R Heat Sink anodized,black 1
119 306-1003770012R Heat Sink anodized,black 1
To Next Page
