Audiolab 8200P - Page 22

ELECTRONIC PARTS LIST
19
8200P
8200P-Electronic Bom-P5/5
R/N P/N PART NAME DISCRIPTION QTY LOCATION
120 306-1003770001QR Heat Sink1 anodized 1
121 306-1003770002QR Heat Sink2 anodized 2
122 306-1003770003QR Heat Sink3 anodized 4
123 306-1027410005R Heat Sink5 anodized,black 4
124 306-1027410003R Heat Sink anodized,black 2
125 812-1376000001R
Connector Socket
1
gilding 4
126 812-1376000004R
Connector Socket
4
gilding 1
127 588-3000066037R Screw M3*6 12
128 588-3000256037R Screw M3*25 8
129 513-3007050080R Wahser φ3*φ7*0.5 Zn 8
130 517-3008080130AR Wahser M3 Ob Φ3.1*Φ4.7*0.8 8
131 500-3050240300AR Nut M3 NI 8
132 018-1400556115-1R Transistor
BC556B PNP TO-92
Fairchild
18
Q102-107.111.130.202-
207.211.230.302.308
133 001-2208920100QR Resistor 0R22 7W+7W 10% 6
R148.284.R146-
147.246-247
134 018-1400546115-1R Transistor
BC546BRL1G TO-92
ON
16
301.307.Q108-
110.112.129.131.208-
210.212.231.229.303.3
05
135 001-3002207010R Resistor
H-FM 2WS 3K3 ±1%
SIZE 11*4.5*0.8MM
2 R121.222
136 034-1115003307-1R Rectifier
DIODE B80C5000A
BRIDGE 80V/5A
DIOTEC
2BR1.2
