- AUDIOLAB STEEL SERIES
Steel S15.2
Professional Power Amplier
Steel S15.2 is a professional power amplier with a
maximum output power of 2 x 1520W @ 8-ohm / 2
x 2300W @ 4-ohm and a maximum bridged output
power of 1 x 4600W (RMS) @ 8-ohm. With a perfor-
mance that stands out for its very low distortion
and high delity, Steel S15.2 is equipped with a
switching-mode power supply. Precisely thanks to
the design of its power supply, the amplier allows
the peak power to follow the dynamic range of the
musical program, being able to reproduce up to
twice the RMS power, without clipping. This trans-
lates, basically, into peaks with much more dynam-
ic range than a conventional-source amplier. As
one would expect in ampliers of this range, the
whole Steel series is equipped with a very ecient
ventilation and has a comprehensive section of
protections, to assure its correct operation in the
most demanding situations.
Specications
Output
• Rated output power (8-Ohm): 2 x 1520W
• Rated output power (4-Ohm): 2 x 2300W
• Rated output power (Bridge @ 8-Ohm): 1 x
4600W
Performance
• Input impedance:
• Balanced: 20Kohm
• Unbalanced: 10Kohm
• Input sensitivity: 0.775Vor1.4V
• Frequency Response: 20Hz~20KHz
• THD: <0.05%
• Damping factor (8-ohms) 10Hz-400Hz: >200
• Crosstalk (at 1Khz): - 75dB
• Signal to noise ratio: >100dB
• Slew rate: 20V/us
• Voltage gain: 38.3dB
• Intermodulation distortion: =/<0.35%
• Protections: Thermal, short circuits, no-load,
on/o muting & RF interference
Connectors & back panel controls
• Power supply connector: Interlock In
• 4 XLR-3 inputs
• 4 Speakon speaker outputs
• Bridge, parallel & input sensibility switch
Physical
• Cooling: Two Front-to-back fans, tempera-
ture controlled speed.
• Net Weight: 7.5 kg. / 16.5 lbs.
• Dimensions: 482x227x88 mm. / 19x9x3.5 in.
