R
L
LOW INPUT
HPF LPF
PROT PWR
BASS BOOST X-OVER
GAIN
HI-INPUT
BRIDGED
LEFT
LEFT RIGHT
RIGHT
20A
GND
REM BATT
POWER
FUSE
SPEAKER OUT
-10-
OPERATION
After initial set-up, the amplifier should not require any
further adjustment unless there is a change in the car
stereo or speaker system with which it is used.
1 Power Indicator LED
The Power Indicator LED will light to indicate that
the unit is connected to the battery and that the Remote
Turn-On terminal is receiving +12 volts, thus turning
on the amplifier.
2 Protection Mode LED
This LED illuminates red to indicate that the self-protection
circuits have been activated and have shut off operation
of the amplifier. The protection circuits may be triggered
by the temperature of the unit rising above a safe level
or by an overload condition. If activated by a rise in
temperature, the unit will resume operation after cooling
off to a normal operating range. If activated by an
7
2
3 4
1
6 5
8
To Next Page
