Audison Prima AP1 D - POWER SUPPLY AND REMOTE CONNECTION; FUSE REPLACEMENT; Power Supply and Remote Connections; Fuse Replacement Procedure

AP1 D /
USER’S MANUAL
39
(Not provided.
Suggested Fuse
30 A delayed)
Max 20 cm / 7.9 in.
15 mm / 0.6 in.
8 AWG Max
6. POWER SUPPLY AND REMOTE CONNECTION / FUSE REPLACEMENT
MUTE onlytoAP4.9bit
REM IN
blue
blue/white
HEX KEY 2,5mm/0.1in.
REM OUT REM OUT
FUSE REPLACEMENT WARNING:
Firmlypresscontactsofeachfuseintro
theirfuse-holderclips
1 x 30A
BLADE FUSE
AP8.9 bit
SOURCE
6
