11. TECHNICAL SPECIFICATION
POWER SUPPLY
Voltage: 7.5 ÷ 15 VDC
Idling current: 1 A
Switched off: <0.05mA
Consumption @ 14.4 VDC 4Ω Max Musical Power (without CPL): 30 A
Consumption @ 14.4 VDC 2Ω Max Musical Power (without CPL): 44 A
Remote IN 7÷15VDC(1mA)
Fuse 30 A
AMPLIFIER STAGE
Distortion - THD @ 1 kHz, 4 Ω, 90% Power: 0.2 %
Distortion - THD @ 100 Hz, 4 Ω, 90% Power: 0.3 %
Bandwidth (-3 dB, 2 V RMS, 4Ω): 16÷40kHz
S/N ratio @ A weighted, 1,5V, Max Power: 100dBA
Damping factor @ 100 Hz, 2 VRMS, 4 Ω: 150
Damping factor @ 1 kHz, 2 VRMS, 4 Ω 160
Input sensitivity PRE IN: Selectable:1,5-3,0-4,5VRMS
Input sensitivity SPEAKER IN: Selectable:3,0–6,0–9,0VRMS
Input impedance: 15kΩ
LOAD IMPEDANCE (MIN):
• Ch: 1 2Ω
MAX POWER 540 W
OUTPUT POWER (RMS) @ 14.4 VDC, 1% THD:
• 1 Ch @ 4Ω: 310Wx1
• 1 Ch @ 2Ω: 540Wx1
OUTPUT POWER (RMS) @ 14.4 VDC, 10% THD:
• 1 Ch @ 4Ω: 380Wx1
• 1 Ch @ 2Ω: 680Wx1
GENERAL REQUIREMENTS
Ambient operating temperature range: 0°Cto55°C(32°Fto131°F)
SIZE / WEIGHT
Max size (mm/in.): 198x45,50x134/7.8x1.8x5.27
Weight (kg/lb): 1.32 / 2.91
SIGNAL CONNECTIONS
PRE IN RCA
SPEAKER IN wired
MUTE(EnergySavingControl) wiredfromAP4.9bit/AP5.9bit
CEA SPECIFICATIONS
Output power @ 4Ω, ⩽1% THD+N, 14.4 V: 310Wx1
SN ratio (ref. 1 W output): 79dBA
