AP1 D /
USER’S MANUAL
43
8. CONTROL PANEL
< 16 Volt CHECK
Flash-LEDRED
POWER ON
LED BLUE
LED RED
< 2 Ohm CHECK
 Flash-LEDRED
70 °C
Flash-LEDRED
INPUT SENSITIVITY
HI MID LO
HI LEVEL INPUT
SENSITIVITY
LO: 3 V RMS
MID: 6 V RMS
HI: 9 V RMS
PRE INPUT
SENSITIVITY
LO: 1.5 V RMS
MID: 3 V RMS
HI: 4.5 V RMS
8
SPEAKER OUTPUT FULL RANGE
POWER@4Ω W(RMS) POWER@2Ω W(RMS)
310 x 1 540 x 1
20 200 2k 20k Hz
FULL RANGEAMP OUTPUT
