AP1 D /
USER’S MANUAL
47
AP TYPE OUTPUT TYPE CUT FILTER FILTER TYPE CUT FREQUENCY TIME ALIGNMENT
*
POWER @ 4Ω POWER @ 2Ω
AP4.9 bit OUT 1 FRONT FULL LEFT HI PASS Linkwitz 80 Hz @12 dB 82,2 cm 70 W 140 W
AP4.9 bit OUT 2 FRONT FULL RIGHT HI PASS Linkwitz 80 Hz @12 dB 116,2 cm 70 W 140 W
AP4.9 bit OUT 3 REAR FULL LEFT HI PASS Linkwitz 80 Hz @12 dB 82,2 cm 70 W 140 W
AP4.9 bit OUT 4 REAR FULL RIGHT HI PASS Linkwitz 80 Hz @12 dB 116,2 cm 70 W 140 W
AP1 D OUT 1 SUB WOOFER LO PASS Linkwitz 80 Hz @12 dB 121,8 cm 280 W 520 W
OUTPUT CONFIGURATION:
= Max power at suggested loads: 800 W
9
Note
