DescriptionDesignation
(process representation)
Prm-Text-Def GSD file
Partial Valve Stroke Test (PVST) was aborted or could not
be started. Remedy: Perform RESET or restart PVST.
Bit: PVST abort
(118) = "Bit: PVST abort"
Release signal OPEN not active: Operation commands in
direction OPEN are disabled.
Bit: Interlock OPEN
(119) = "Bit: Interlock OPEN"
Release signal CLOSE not active: Operation commands in
direction CLOSE are disabled.
Bit: Interlock CLOSE
(120) = "Bit: Interlock CLOSE"
Bypass of interlock function is active.
Bit: Interlock by-pass
(121) = "Bit: Bypass Interlock"
No reaction detected at actuator output drive.
Bit: No reaction (fault)
(122) = "Bit: Fault no reaction"
Config. error of REMOTE interface active.
Bit: Config. error REMOTE
(123) = "Bit: Config error remote"
Warning: Limit value for torque warning in direction OPEN
exceeded.
Bit: Torque warn. OPEN
(124) = "Bit: Torque wrn OPEN"
Warning: Limit value for torque warning in direction CLOSE
exceeded.
Bit: Torque warn. CLOSE
(125) = "Bit: Torque wrn CLOSE"
Warning: Voltage of RTC button cell too low.
Bit: RTC button cell
(126) = "Bit: RTC button cell"
Warning: FO cable connection is not available.
Bit: Wrn FOC connection
(127) = "Bit: Wrn FOC connection"
Actual actuator position (0 – 1,000 per mil)
u16: Actual position
(128) = "u16: Actual position"
Analogue input 1
u16: Input AIN 1
(129) = "u16: Input AIN 1"
Analogue input 2
u16: Input AIN 2
(130) = "u16: Input AIN 2"
Torque in direction CLOSE, unit in %
u16: Torque CLOSE %
(131) = "u16: Torque CLOSE %"
Torque in direction OPEN, unit in %
u16: Torque OPEN %
(132) = "u16: Torque OPEN %"
Torque in direction CLOSE, unit in Nm
u16: Torque CLOSE Nm
(133) = "u16: Torque CLOSE Nm"
Torque in direction OPEN, unit in Nm
u16: Torque OPEN Nm
(134) = "u16: Torque OPEN Nm"
Torque in direction CLOSE, unit in ft-lb
u16: torque CLOSE ft-lb
(135) = "u16: torque CLOSE ft-lb"
Torque in direction OPEN, unit in ft-lb
u16: Torque OPEN ft-lb
(136) = "u16: Torque OPEN ft-lb"
Actual torque value
u16: Torque
(137) = "u16: Torque"
Actual actuator position (0 – 100 percent)
Actual position 0-100 %
(139) = "u16: Actual Position 0-100%"
Parameter not available(160) = "i16: Actual position"
Parameter not available(161) = "i16: Input AIN 1"
Parameter not available(162) = "i16: Input AIN 2"
Parameter not available(163) = "i16: Torque CLOSE %"
Parameter not available(164) = "i16: Torque OPEN %"
Parameter not available(192) = "float: Actual position"
Parameter not available(193) = "float: Input AIN 1"
Parameter not available(194) = "float: Input AIN 2"
Parameter not available(195) = "float: T CLOSE %"
Parameter not available(196) = "float: T OPEN %"
Parameter not available(197) = "float: T CLOSE Nm"
Parameter not available(198) = "float: T OPEN Nm"
Parameter not available(199) = "float: T CLOSE lbs/ft."
Parameter not available(200) = "float: T OPEN lbs/ft."
Parameter not available
Bit: Cylinder pressure max.
(201) = "Cylinder printing max."
Parameter not available
Bit: Hydraulic pressure
fault
(202) = "Hydraulics fault"
Parameter not available
Bit: Wrn hydraulics
(203) = "Hydraulics warning"
Safe ESD function (Emergency Shut Down) is active.
Bit: Safe ESD
1)
(204) = "Safe ESD"
Safe STOP function is active.
Bit: Safe STOP
1)
(205) = "Safe Stop"
A SIL fault has occurred (collective signal).
Bit: SIL fault
1)
(206) = "SIL fault"
A SIL function is active.
Bit: SIL function active
1)
(207) = "SIL function active"
(PVST) Partial Valve Stroke Test should be executed
Bit: PVST required
(208) = "PVST required"
Mechanic maintenance requirement
Bit: Maintenance mechan-
ics
(209) = "Mechanic lifetime"
16
Actuator controls
Commissioning AC 01.2/ACExC 01.2 Profibus DP
