3.6.2. Settable (user definable) signals
Table 2: Description of the parameter settings
DescriptionDesignation
(process representation)
Prm-Text-Def GSD file
–(0) = "Bit: Reserved"
For limit seating: Limit switch operated in direction CLOSE
For torque seating: Torque switch and limit switch operated
in direction CLOSE
Bit: End p. CLOSED
(1) = "Bit: End p. CLOSED"
For limit seating: Limit switch operated in direction OPEN
For torque seating: Torque switch and limit switch operated
in direction OPEN
Bit: End p. OPEN
(2) = "Bit: End p. OPEN"
End position CLOSED reached or intermediate position
reached
(The intermediate position is only indicated if parameter
Signal interm. pos. M0167 = OPEN/CLOSED = On.)
Signal blinking: Actuator runs in direction CLOSE.
Bit: EP CLOSED, blink
(3) = "Bit: End p. CLOSED, blink"
End position OPEN reached or intermediate position
reached.
(The intermediate position is only indicated if parameter
Signal interm. pos. M0167 = OPEN/CLOSED = On.)
Signal blinking: Actuator runs in direction OPEN.
Bit: EP OPEN, blink
(4) = "Bit: End p. OPEN, blink"
The position setpoint is is within max. error variable (outer
dead band). Is only signalled if Profibus DP master has set
the Fieldbus SETPOINT bit (process representation output).
Bit: Setpoint reached
(5) = "Bit: Setpoint reached"
An operation command in direction CLOSE is performed
via fieldbus: Fieldbus CLOSE or Fieldbus SETPOINT (pro-
cess representation output).This bit remains also set during
operation pauses (e.g. due to the dead time or the reversing
prevention time).
Bit: Running CLOSE
(6) = "Bit: Running CLOSE"
An operation command in direction OPEN is performed via
fieldbus: Fieldbus OPEN or Fieldbus SETPOINT (process
representation output).This bit remains also set during op-
eration pauses (e.g. due to the dead time or the reversing
prevention time).
Bit: Running OPEN
(7) = "Bit: Running OPEN"
Selector switch is in position LOCAL.
Bit: Sel. sw. LOCAL
(8) = "Bit: Selector sw. LOCAL"
Selector switch is in position REMOTE.
Bit: Sel. sw. REMOTE
(9) = "Bit: Sel. sw. REMOTE"
Selector switch is in position OFF.
Bit: Sel. sw. OFF
(10) = "Bit: Sel. sw. OFF"
Limit switch operated in end position CLOSED
Bit: Limit sw. CLOSED
(11) = "Bit: Limit sw. CLOSED"
Limit switch operated in end position OPEN
Bit: Limit sw. OPEN
(12) = "Bit: Limit sw. OPEN"
Torque switch operated in direction CLOSE
Bit: Torque sw.CLOSE
(13) = "Bit: Torque sw. CLOSE"
Torque switch operated in direction OPEN
Bit: Torque sw.OPEN
(14) = "Bit: Torque sw. OPEN"
Collective signal 05:
The device is ready for remote control.
No AUMA warnings, AUMA faults or signals according to
NAMUR are present.
Bit: Device ok
(15) = "Bit: Device ok"
Collective signal 10:
Indication according to NAMUR recommendation NE 107
Actuator function failure, output signals are invalid.
Bit: Failure
(16) = "Bit: Failure"
Collective signal 08:
Indication according to NAMUR recommendation NE 107
The actuator is being worked on; output signals are tempor-
arily invalid.
Bit: Function check
(17) = "Bit: Function check"
Collective signal 07:
Indication according to NAMUR recommendation NE 107
Actuator is operated outside the normal operation conditions.
Bit: Out of spec.
(18) = "Bit: Out of spec."
Collective signal 09:
Indication according to NAMUR recommendation NE 107
Recommendation to perform maintenance.
Bit: Maintenance requ.
(19) = "Bit: Maintenance requ."
12
Actuator controls
Commissioning AC 01.2/ACExC 01.2 Profibus DP
