DescriptionDesignation
(process representation)
Prm-Text-Def GSD file
Collective signal 03:
Contains the result of a disjunction (OR operation) of all
faults.
The actuator cannot be operated.
Bit: Fault
(20) = "Bit: Fault"
Collective signal 02:
Contains the result of an OR disjunction of all warnings.
Bit: Warnings
(21) = "Bit: Warnings"
Collective signal 04:
Contains the result of a disjunction (OR-operation) of the
signals, forming the "Not ready REMOTE" group.
The actuator cannot be operated from REMOTE.
Bit: Not ready REMOTE
(22) = "Bit: Not ready REMOTE"
The actuator is in off-time (e.g. stepping mode or reversing
prevention time).
Bit: Op. pause active
(23) = "Bit: Op. pause active"
The actuator is within the set stepping range.
Bit: Start step mode
(24) = "Bit: Start step mode"
Actuator is running (output drive is moving)
Hard wired collective signal consisting of signals:
●
(26) Bit: Running LOCAL
●
(27) Bit: Running REMOTE
●
(28) Bit: Handwheel oper.
Bit: Actuator running
(25) = "Bit: Actuator running"
Output drive rotates due to operation command from LOCAL.
Bit: Running LOCAL
(26) = "Bit: Running LOCAL"
Output drive rotates due to operation command from RE-
MOTE.
Bit: Running REMOTE
(27) = "Bit: Running REMOTE"
Output drive rotates without electric operation command
(manual operation).
Bit: Handwheel oper.
(28) = "Bit: Running via handw."
The actuator is in an intermediate position e.g. neither in
end position OPEN nor in end position CLOSED.
Bit: In interm. position
(29) = "Bit: In interm. position"
The failure behaviour is active.
Bit: Failure behav. act.
(30) = "Bit: Failure behav. active"
Intermediate position 1 reached
Bit: Interm. pos. 1
(31) = "Bit: Intermediate pos. 1"
Intermediate position 2 reached
Bit: Interm. pos. 2
(32) = "Bit: Intermediate pos. 2"
Intermediate position 3 reached
Bit: Interm. pos. 3
(33) = "Bit: Intermediate pos. 3"
Intermediate position 4 reached
Bit: Interm. pos. 4
(34) = "Bit: Intermediate pos. 4"
Intermediate position 5 reached
Bit: Interm. pos. 5
(35) = "Bit: Intermediate pos. 5"
Intermediate position 6 reached
Bit: Interm. pos. 6
(36) = "Bit: Intermediate pos. 6"
Intermediate position 7 reached
Bit: Interm. pos. 7
(37) = "Bit: Intermediate pos. 7"
Intermediate position 8 reached
Bit: Interm. pos. 8
(38) = "Bit: Intermediate pos. 8"
A high signal (+24 V DC) is present at digital input 1.
Bit: Input DIN 1
(39) = "Bit: Input DIN 1"
A high signal (+24 V DC) is present at digital input 2.
Bit: Input DIN 2
(40) = "Bit: Input DIN 2"
A high signal (+24 V DC) is present at digital input 3.
Bit: Input DIN 3
(41) = "Bit: Input DIN 3"
A high signal (+24 V DC) is present at digital input 4.
Bit: Input DIN 4
(42) = "Bit: Input DIN 4"
A high signal (+24 V DC) is present at digital input 5.
Bit: Input DIN 5
(43) = "Bit: Input DIN 5"
A high signal (+24 V DC) is present at digital input 6.
Bit: Input DIN 6
(44) = "Bit: Input DIN 6"
Parameter not available
Bit: Input DIN 7
(45) = "Bit: Input DIN 7"
Parameter not available
Bit: Input DIN 8
(46) = "Bit: Input DIN 8"
No valid communication via fieldbus (despite available con-
nection)
Bit: FailState fieldbus
(47) = "Bit: FailState fieldbus"
The actuator is controlled via the I/O interface (parallel).
Bit: I/O interface
(48) = "Bit: I/O interface"
Operation mode EMERGENCY is active (EMERGENCY
signal was sent).
Bit: EMCY behav. act.
(49) = "Bit: EMCY behav.act."
Operation mode EMERGENCY stop is active (EMERGENCY
stop button pressed).
Bit: EMCY stop active
(50) = "Bit: EMCY stop active"
Operation mode Service (via Bluetooth) is active.
Bit: Service active
(51) = "Bit: Service active"
Actuator is interlocked.
Bit: Interlock active
(52) = "Bit: Interlock active"
Selector switch is in position Local control (LOCAL) or 0
(OFF).
Bit: Sel. sw. not REMOTE
(53) = "Bit: Sel. sw. not REMOTE"
Manual operation is active (handwheel is engaged); optional
signal
Bit: Handwheel active
(54) = "Bit: Handwheel active"
13
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Commissioning
