ExplanationSetting valueDefaultAccessParametersTypeNo.
Failure position in percent
Min = 0 [0.1 %]500R/W
Failure position
U1615-5
Max = 1000 [0.1 %]
Failure position of multiport
valve
Min = 0 [0.1 %]500R/W
Failure position MPV
U1615-6
Max = 1000 [0.1 %]
Table 58: EMERGENCY behaviour
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 26 bytes
Failure reaction EMERGENCY.
The EMERGENCY failure reac-
tion defines the actuator beha-
viour once the EMERGENCY
signal is initiated.
1 : Good signal first
1R/W
Failure reaction EMCY
enum16-1
2 : Immediately active
Determines the availability of
EMERGENCY behaviour de-
pending on the selector switch
position Local or Remote
0 : Remote only
0R/W
EMCY operation mode
enum16-2
1 : Remote and local
Failure source for EMERGENCY
behaviour
1 : I/O interface
3R/W
EMCY failure source
enum16-3
2 : Fieldbus interface
3 : I/O or fieldbus
4 : Active interface
Actuator reaction in EMER-
GENCY operation mode
0 : STOP
0R/W
EMCY operation
enum16-4
1 : CLOSE
2 : OPEN
3 : Approach EMCY pos.
Setting the EMERGENCY posi-
tion
Min = 0 [0.1 %]0R/W
EMCY position
U1616-5
Max = 1000 [0.1 %]
By-passing the torque monitor-
ing in EMERGENCY operation
mode
0 : Off
0R/W
By-pass torque
enum16-6
1 : On
By-passing the thermal monitor-
ing in EMERGENCY operation
mode
0 : Off
0R/W
Thermal by-pass
enum16-7
1 : On
By-passing the timer function in
EMERGENCY operation mode
0 : Off
0R/W
By-pass timer
enum16-8
1 : On
By-pass of operation profile in
EMERGENCY operation mode
0 : Off
0R/W
By-pass operat.profile
enum16-9
1 : On
By-pass of interlock function in
operation mode EMERGENCY
0 : Off
0R/W
By-pass Interlock
enum16-10
1 : On
By-pass of local STOP function
in EMERGENCY operation
mode
0 : Off
0R/W
By-pass Local STOP
enum16-11
1 : On
68
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profibus DP
