Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.TypeDesignationRef. no.
Sub-assemblyPotentiometer as position transmitter556.0Sub-assemblyDrive shaft005.0
Sub-assemblyPotentiometer without slip clutch556.1Sub-assemblyMotor coupling005.1
Sub-assemblyHeater557.0Sub-assemblyManual drive coupling005.3
Sub-assemblyBlinker transmitter including pins at wires
(without impulse disc and insulation plate)
558.0Worm wheel006.0
Sub-assemblyElectromechanical control unit with
switches, including torque switching heads
and switches
559.01Sub-assemblyManual gearing009.0
Sub-assemblyElectronic control unit with magnetic limit
and torque transmitter (MWG)
559.02Sub-assemblyTorque lever017.0
Sub-assemblySwitch stack for direction OPEN560.01Gear segment018.0
Sub-assemblySwitch stack for direction CLOSE560.02Sub-assemblyCrown wheel019.0
Sub-assemblySwitch for limit/torque560.1Drive pinion II for torque switching022.0
Switch case for direction OPEN560.21Sub-assemblyOutput drive wheel for limit switching023.0
Switch case for direction CLOSE560.22Sub-assemblyDrive wheel for limit switching024.0
Sub-assemblyRWG position transmitter566.0Sub-assemblyLocking plate025.0
Sub-assemblyPotentiometer for RWG without slip clutch566.1Sub-assemblyCable for protective earth058.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyMotor (incl. ref. no. 079.0)070.0
Sub-assemblyCable set for RWG566.3Sub-assemblyPlanetary gearing for motor drive079.0
Sub-assemblySlip clutch for potentiometer567.1Sub-assemblyReduction gearing155.0
Sub-assemblyEx plug/socket connector with terminal
blocks (KES)
573.0Sub-assemblyCover500.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblyPin carrier without pins502.0
Pin for motor coupling583.1Sub-assemblyPin for controls505.0
Sub-assemblyRetaining spring for motor coupling584.0Sub-assemblyPin for motor506.0
Sub-assemblyOutput drive flange with end stop596.0Sub-assemblyCoupling525.0
Sub-assemblyCover607.0Terminal frame (without terminals)528.0
Sub-assemblyScrew plug for end stop612.0Sub-assemblyEnd clamp529.0
Sub-assemblyEWG position transmitter614.0Sub-assemblyTerminals for motor/controls533.0
MWG 05.03 cover627.0Sub-assemblyScrew plug539.0
Sub-assemblyPinion shaft629.0Sub-assemblyHandwheel with ball handle542.0
SetSeal kit, smallS1Sub-assemblyMechanical position indicator553.0
SetSeal kit, largeS2Socket carrier for motor plug/socket con-
nector with cable harness
554.0
80
SQEx 05.2 SQEx 14.2 / SQREx 05.2 SQREx 14.2 Control unit: electronic (MWG)
Spare parts ACExC 01.2 Non-Intrusive Modbus TCP/IP
