Page #51 background imageLoading...
Page #51 background image
RemedyDescription/causeIndication on display
Press push button Details to display a list
of individual indications.
Collective signal 22:
Configuration error has occurred.
Config. error REMOTE
AUMA service
Press push button Details to display a list
of individual indications.
Collective signal 14:
Internal error has occurred.
Internal error
Perform one of the following measures:
Issue operation command in direction
OPEN.
Set selector switch to position Local con-
trol (LOCAL) and reset fault indication via
push button RESET.
Torque fault in direction CLOSE
Torque fault CLOSE
Perform one of the following measures:
Issue operation command in direction
CLOSE.
Set selector switch to position Local con-
trol (LOCAL) and reset fault indication via
push button RESET.
Torque fault in direction OPEN
Torque fault OPEN
Test/connect phases.
When connecting to a 3-ph AC system and
with internal 24 V DC supply of the elec-
tronics: Phase 2 is missing.
When connecting to a 3-ph or 1-ph AC
system and with external 24 V DC supply
of the electronics: One of the phases L1,
L2 or L3 is missing.
Phase fault
Correct the sequence of the phase conductors
L1, L2 and L3 by exchanging two phases.
The phase conductors L1, L2 and L3 are
connected in the wrong sequence.
Only applicable if connected to a 3-ph AC
system.
Incorrect phase seq
Check mains voltage.
Check parameter Tripping time M0172,
extend time frame if required.
Due to insufficient mains quality, the controls
cannot detect the phase sequence (sequence
of phase conductors L1, L2 and L3) within the
pre-set time frame provided for monitoring.
Mains quality
Cool down, wait.
If the fault indication display persists after
cooling down:
-
Set selector switch to position Local
control (LOCAL) and reset fault indic-
ation via push button RESET.
Check fuses.
Motor protection tripped
Thermal fault
Check movement at actuator.No actuator reaction to operation commands
within the set reaction time.
Fault no reaction
Table 13: Not ready REMOTE and Function check (collective signal 04)
RemedyDescription/causeIndication on display
Check operation commands (send one
operation command only).
Set parameter Positioner to Function act-
ive.
Check setpoint.
Press push button Details to display a list
of individual indications.
Collective signal 13:
Possible causes:
Several operation commands (e.g. OPEN
and CLOSE simultaneously, or OPEN and
SETPOINT operation simultaneously)
A setpoint is present and the positioner is
not active
For fieldbus: Setpoint exceeds 100.0 %
Wrong oper. cmd
Set selector switch to position REMOTE.Selector switch is not in position REMOTE.
Sel. sw. not REMOTE
Exit service software.Operation via service interface (Bluetooth) and
service software AUMA CDT.
Service active
Check setting and status of function <Local
controls enable>.
Actuator is in operation mode Disabled.
Disabled
51
SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive Corrective action
