Page #61 background imageLoading...
Page #61 background image
Electronic device ID with order and product data
Logging of operating data: A resettable counter and a lifetime counter each for:
-
Motor running time, number of starts, torque switch trippings in end positions CLOSED,
limit switch trippings in end position CLOSED, torque switch trippings in end position
OPEN, limit switch trippings in end position OPEN, torque faults CLOSE, torque faults
OPEN, motor protection trippings
Time-stamped event report with setting, operation and fault history:
-
Status signals in compliance with NAMUR recommendation NE 107: "Failure",
Function check", "Out of specification", "Maintenance required"
Torque characteristics
-
3 torque characteristics (torque-travel characteristic) for opening and closing directions,
can be saved separately. Torque characteristics stored can be shown on the display.
Diagnostic functions
Standard:
AUMA plug/socket connector (S) with screw-type connection and M-threads
Options:
Pg-threads, NPT-threads, G-threads, special threads
Gold-plated control contacts (pins and sockets)
Parking frame for wall mounting of the disconnected plug
Protection cover for plug compartment (when plug is removed)
Electrical connection
Refer to name plateWiring diagram
The reversing contactors are designed for a lifetime of 2 million starts.1)
For the assignment of AUMA power classes, please refer to electrical data on actuator.2)
All input signals must be supplied with the same potential.3)
Not possible for low temperature versions with heating system4)
Not possible in combination with PTC tripping device5)
Further options for Non-intrusive version with MWG in the actuator
Setting limit and torque switching via the controls local controls
Galvanically isolated analogue output E6 = 0/4 20 mA (max. load 500 Ω), only possible in
combination with output contacts
Torque feedback signal
12.3. Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
2,000 m above sea level
for > 2,000 m above sea level, please contact AUMA
Installation altitude
Up to 100 % relative humidity over the entire permissible temperature rangeHumidity
Standard:
Open-close duty: 25 °C to +70 °C
Modulating duty: 25 °C to +60 °C
For actual version, refer to actuator/controls name plate.
Ambient temperature
Standard: IP68 with AUMA 3-phase AC motor/1-phase AC motor
According to AUMA definition, enclosure protection IP68 meets the following requirements:
Depth of water: maximum 8 m head of water
Duration of continuous immersion in water: Max. 96 hours
Up to 10 operations during continuous immersion
Modulating duty is not possible during continuous immersion.
For actual version, refer to actuator/controls name plate.
Enclosure protection according
to EN 60529
Pollution degree 4 (when closed) according to EN 50178Pollution degree
1 g, from 10 to 200 Hz
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength
may not be derived from this.
Vibration resistance according
to IEC 6006826
61
SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive Technical data
