able 6:
Setting values
Default values f
or version
Menu
Parameter
s
USA
Europe
Yellow
Green
Yellow/green
Green
Yellow
M0838
Colour
ind.light
1
Red
Blue
Purple
Blue
Red
M0839
Colour
ind.light
2
Red
Yellow
Orange
Yellow
Red
M0840
Colour
ind.light
3
Red
Blue
Purple
Blue
Red
M0841
Colour
ind.light
4
Green
Red
Orange
Red
Green
M0842
Colour
ind.light
5
26
Actuator controls
Indications
ACV 01.2/A
CVExC 01.2
25
27
Table of Contents
Default Chapter
1
Assignment of Analogue Output
1
Signal Range of Analogue Output
1
Adjustment of Analogue Output
1
Table of Contents
2
Safety Instructions
8
Basic Information on Safety
8
Range of Application
8
Warnings and Notes
9
References and Symbols
9
Identification
10
Name Plate
10
Short Description
11
Operation
13
Local Actuator Operation
13
Actuator Operation from Remote
13
Menu Navigation Via Push Buttons (for Settings and Indications)
14
Menu Layout and Navigation
15
User Level, Password
16
Password Entry
16
Password Change
17
Language in the Display
17
Language Change
17
Indications
19
Indications During Commissioning
19
Indications in the Display
19
Feedback Indications from Actuator and Valve
20
Status Indications According to AUMA Classification
22
Status Indications According to NAMUR Recommendation
23
Indication Lights of Local Controls
25
Indication Lights: Change Colour
25
Signals (Output Signals)
27
Status Signals Via Output Contacts (Digital Outputs)
27
Assignment of Outputs
27
Coding the Outputs
27
Configurable Status Signals
27
Analogue Signals (Analogue Outputs)
28
Signal Range of Analogue Output 1
29
Adjustment of Analogue Output 2
30
Assignment of Analogue Output 2
30
Signal Range of Analogue Output 2
30
Operation
32
Operation Mode off
32
Operation Mode Local
32
Push-To-Run Operation or Self-Retaining Local
32
Operation Mode Remote
33
Push-To-Run Operation or Self-Retaining Remote
33
Operation Mode EMERGENCY
34
Operation Mode EMERGENCY Stop
34
Operation Mode Disabled
35
Operation Mode Service
35
Basic Settings for Commissioning
36
Type of Seating for End Positions
36
Type of Seating: Set
36
Torque Switching
37
Torque Switching: Set
38
Limit Switching
39
Limit Switching: Set
39
Date and Time
41
Display Formats
41
Date Format
41
Time Format
41
Number Format
41
Torque Unit
42
Temperature Unit
42
Position Units
42
Process Factor Units
43
Analogue Working Value Units (AIN)
43
Analogue Signal Output Units (AIN)
44
Contrast
44
Application Functions
45
Speed Functions
45
Speed Source for Local Operation and Remote Operation
45
Speed for Constant (Internal) Speed Setpoint: Set
46
Speed Range for Analogue Input: Set
47
Speed Reduction before Reaching End Positions OPEN/CLOSED
47
Intermediate Positions (Pivot Points)
48
Intermediate Positions (Pivot Points): Define
48
Signal Behaviour of Intermediate Positions: Set
48
Tions 8.2. Intermediate Positions (Pivot Points)
48
Hysteresis for Intermediate Positions: Set
49
Operation Profile (Operation Behaviour) for Intermediate Positions
50
Operation Profile: Activate
50
Operation Profile for Intermediate Positions (Pivot Points): Set
50
Off Times for Intermediate Positions (Pivot Points): Set
51
Two-Wire Control
51
Positioner (Operation Mode Remote SETPOINT)
52
Positioner: Activate
52
Adaptive Behaviour: Switch on or off
53
Overrun (Inner Dead Band): Set Manually
53
Max. Error Variable (Outer Dead Band): Set Manually
54
Dead Time: Set
54
Hysteresis for Positioner: Set
54
Closing Fully/Opening Fully (End Position Tolerance for Setpoint)
54
Setting Range: Limit
55
Speed Reduction before Reaching Setpoint Position
56
Change-Over between OPEN - CLOSE Control and Setpoint Control
56
Input of Setpoint Position
57
Input Range of Setpoint Position
57
Split Range Operation
57
Process Controller
58
Process Controller Activation
59
Process Controller: Set Modulating Behaviour
59
Setpoint Source (Input for Process Setpoint)
60
Behaviour on Loss of Process Setpoint
61
Inverse Operation
61
Internal Process Setpoint
61
Setting Procedure
62
Proportional Amplification Kp: Set
62
Reset Time Ti: Set
62
Rate Time Td: Set
62
Actual Value Source (Input for Actual Process Value)
63
Speed Source for Actual Process Value
63
Stepping Mode
63
Stepping Mode: Activate
64
Operation Mode for Stepping Mode
64
Start and End of Stepping Mode
65
On Times and off Times
65
By-Pass Function
65
Bypass Function: Activate
67
By-Pass Application: Configure
67
Automatic Deblocking
67
Automatic Deblocking Function: Activate
68
Operation Time for Operation in Opposite Direction: Set
68
Number of Deblocking Attempts: Set
68
Tolerance Range: Set
69
Synchronous Link
69
Synchronous Link Function: Activate
70
Role (Master Actuator/Slave Actuator): Define
70
Deviation: Set
71
Heater System and Heaters
71
Heater System Within the Actuator Controls
71
Heater on Control Unit (Actuator)
71
Motor Heater
72
Failure Functions
73
Reversing Prevention Time
73
Failure Behaviour on Loss of Signal
73
Failure Behaviour Initiation on Loss of Signal
73
Failure Source (Failure Reason) for a Failure Operation: Set
73
Failure Operation (Reaction of the Actuator) on Loss of Signal
74
Failure Position: Define
74
Speed for Safety Operation: Set
75
Delay Time: Set
75
EMERGENCY Behaviour
75
EMERGENCY Behaviour: Activate
76
EMERGENCY Failure Reaction
76
Failure Source (Failure Reason) for an EMERGENCY Operation: Set
77
Operation Mode for EMERGENCY Behaviour
77
EMERGENCY Operation
77
EMERGENCY Position
78
EMERGENCY Speed
78
Torque Switching: By-Pass
78
Motor Protection: By-Pass
78
Stepping Mode: By-Pass
79
Operation Profile: By-Pass
79
Interlock: By-Pass
79
Local Stop: By-Pass
79
Delay Time for EMERGENCY Operation
80
Enabling Local Controls
80
Enabling Function: Activate
80
Enabling Function Behaviour
81
Priority REMOTE
81
Priority REMOTE: Activate
81
Priority REMOTE Behaviour
82
Interlock (Enabling Operation Commands)
82
Interlock: Activate
83
Failure Source of Interlock Enable Signal: Set
83
Operation Mode for Interlock
83
Interlock Behaviour (Running Direction)
83
Local Stop
84
Behaviour
84
EMERGENCY Stop Function
84
Partial Valve Stroke Test (PVST)
85
PVST: Activate
86
PVST Source: Set
86
Operation Mode for PVST
86
Behaviour for PVST: Define
86
Partial Stroke for PVST: Set
87
PVST Monitoring Time: Set
87
PVST Operating Time: Set
87
PVST Reverse Time: Set
87
PVST Reminder
87
Monitoring Functions
89
Torque Monitoring
89
Torque By-Pass
89
Torque Limitation of Torque By-Pass
90
Motor Protection Monitoring (Thermal Monitoring)
91
Type of Duty Monitoring (Motor Starts and Running Time)
91
Operating Time Monitoring
93
Reaction Monitoring
93
Motion Detector
94
Motion Detector: Activate
94
Detection Time Dt
94
Travel Difference DX
95
Delay Time
95
Vibration/Oscillation Monitoring
95
Monitoring of Electronics Power Supply
96
Temperature Monitoring
96
Heater System/Heater Monitoring
96
Verification of Sub-Assemblies
97
Phase Failure Monitoring
98
Functions: Activate and Enable
99
Activate Functions
99
Enable Functions
99
Direction of Rotation
100
Factory Setting
100
Service Functions
100
Data Export
101
Data Import
101
Languages: Reload
101
Actual Configuration: Accept
102
Firmware Update
102
Service Software
102
Diagnostic Bluetooth Connection
104
Diagnostics
104
Electronic Device ID
104
Diagnostic Interface
105
Diagnostic Position Transmitter Potentiometer
106
Diagnostic on Time Monitoring
107
Diagnostic Position Transmitter MWG
107
Diagnostic Position Transmitter RWG
107
Diagnostic Positioner
107
Diagnostic FO Cable
108
Diagnostic Process Controller
108
Simulation (Inspection and Test Function)
108
13.11.1. Actuator Signals
108
13.11.2. Interface Signals
109
Plant Asset Management
110
Operating Data
110
Event Report
111
Characteristics
112
Torque-Travel Characteristic
112
Position-Time Characteristic
114
Temperature-Time Characteristic
115
Histograms
115
Motor Running Time-Position (Histogram)
115
Motor Running Time-Temperature (Histogram)
116
Frequency-Acceleration (Histogram)
117
Motor Running Time-Torque (Histogram)
117
Maintenance (Information and Signals)
118
Device Temperatures: Display
120
Operating Times: Display
120
Oscillation/Vibration Indication
120
Corrective Action
122
Fault Indications and Warning Indications
122
Primary Fuses
122
Appendix
129
Selection Overview for Output Contacts and Indication Lights (Digital Outputs DOUT)
129
Selection Overview of Binary Signals for Digital Inputs (DIN)
131
Index
132
Parameter Index
136
Addresses
141
