Autel MaxiBAS BT608 - Power Sources; Technical Specifications

8
2.2.2 Power Sources
The VCI device can receive power from following sources:
 Vehicle Power
 AC/DC Power Supply
Vehicle Power
The VCI device operates on 12/24 Volt vehicle power, which is powered by
the vehicle data connection port. The device powers on whenever it is
connected to an OBD II/EOBD-compliant data link connector (DLC).
AC/DC Power Supply
The VCI device can be powered from a wall socket using the AC/DC power
adapter. The flashlight on the VCI device can by powered by this way.
2.2.3 Technical Specifications
Item
Description
Communications
 BLE + EDR
 USB 2.0
Wireless Frequency
2.4 GHz
Input Voltage Range
6 to 36 V DC
Supply Current
150 mA @ 12 V DC
Operating Temperature
-10°C to 50°C (14 ° F to 122 ° F)
Storage Temperature
-40°C to 80°C (-40 ° F to 176 ° F)
Dimensions (L x W x H)
89.89 mm (3.53”) x 46.78 mm (1.84”) x 21 mm
(0.82”)
Weight
70.7 g (0.156 lb.)
Built-in Battery
3.7 V Lithium Battery
Light
White LED
