KITCHEN APPLIANCES
Thetford K1520
The K1520 oven is fitted with three gas burners, one 230V hotplate and a gas oven. The gas burners are fully
adjustable between simmer and full flame, and the oven ranges from 130˚C to 240˚C.
The electric hotplate has six temperature settings. The oven, grill and burners operate o the on-board LPG
supply, the 230V electric hotplate can only be used when the vehicle is plugged into a 230V electrical supply.
Each burner will support pans between 100mm and 200mm in diameter. Care should be taken not to overload
the appliance as performance may be reduced. When using small pans the flame should be adjusted so as not to
spread beyond the base of the pan as this will reduce the eciency of the burner.
1. Glass lid
2. Pan supports
3. Gas burners
4. Spark ignition (optional)
5. Grill
6. Oven
7. Oven shelf
8. Grill pan
9. Control panel
10. Electric hotplate (dual fuel only)
Using the burners
Turning on:
• Push and turn the control knob.
• Turn the control knob anti-clockwise to the full rate position.
• For spark ignition models: Push the ignition button.
• Keep the control knob pressed for about ten to fifteen seconds and then release it.
• Adjust the height of the flame.
Turning o:
• Turn the control knob clockwise to the O position to turn o the burner.
