5. Slide the holding tank into position
through access door (fig. 5).
6. Make sure the holding tank is secured by
the retaining clip. (fig. 6).
7. Open the waterfill door and add 50 ml of
Aqua Rinse. Aqua Rinse results in a better
flush and improves the hygiene of the
toilet. Then fill the watertank with fresh
water using a jerrycan or a hose. Tank
capacity is 7 litres (fig. 7).
10
11
9
9a
13
14
11a
12
Operation
8. Turn the bowl in the most comfortable
position (fig. 8).
9. C-200 CW only: Before using the toilet it
is recommended to flush some water into
the bowl by lifting and pressing down the
flush handle (fig. 9).
9a. C-200 CWE & CS only: Before using the
toilet it is recommended to flush some
water into the bowl by pressing and
releasing the flush button (fig. 9a).
10. The toilet may be used with the blade
open or closed. Pull valve handle towards
you to open (fig. 10).
thetford cassette toilet
