equipment details
119
Important Warning Notice! If your toilet
has its own flush-water tank, please
make sure that you do not travel with
a flush-water tank that is too full. Do
not travel with water in the toilet bowl.
Failure to adhere to this notice may
result in water damage to your caravan
or motor home.
Using the toilet with optional features
13. Electric Blade: Push the electric blade
button on the control display to electrically
open or close the blade. In the case of
failure, you can manually open or close the
blade by sliding the small handle under the
toilet bowl sideways.
14. Automatic Ventilator: The ventilator
automatically starts when the control
panel is activated (by pressing the flush
button) and will automatically shut off after
approximately 5 minutes. The Automatic
Ventilator Indicator will flash until automatic
shut-off occurs. If you want to stop the
ventilator, press the Automatic Ventilator
button. If you want to re-start the ventilator,
press the button again (the LED will start
flashing again).
15. Flush Water Tank Level Indicator (only for
toilets with own flush-water tank): When
the Flush Water Tank Level Indicator lights
up, refill the flush-water tank, as only
about 1.5 litres of water is left in the tank,
which is sufficient for approximately 2
flushes.
Emptying
TheWasteHoldingTankhasacapacityof18
litres and requires emptying when the red light
(LED) on the toilet control display lights up,
whentheWasteHoldingTankonlyhascapacity
for approximately 2 more litres, which is no
more than two to three further uses. Make sure
that the blade is closed. Open the access door
located outside the vehicle, pull the safety catch
upwardsandremovetheWasteHoldingTank.
16.PlacetheWasteHoldingTankinanupright
position(Pull-OutHandleatthetop,
Wheels at the bottom). Slide the handle
sideways - to the front of the tank - until it
snaps out of its locked position.
17. Pull the handle up and wheel the Waste
HoldingTanktoanauthorisedwaste
disposal point.
18. Push the handle back into its locked
position. Turn the emptying spout upwards
andremovethecapfromthespout.Hold
theWasteHoldingTankinsuchawaythat
during emptying you can operate the vent
plunger with your thumb. To empty the tank
without splashing, depress the vent plunger
while emptying the tank. After emptying,
rinse the tank and blade thoroughly with
water.
Warning! Do not seriously shake
the tank or use high pressure water
cleaners. This may cause damage to the
tank’s interior.
Note. The vent plunger should only be
depressed once the emptying spout is
pointing downwards. Prepare the toilet
for re-use if required. Slide the Waste
Holding Tank into the toilet and close
the access door.
