The following table shows details of the fuse(s)
located at the Leisure battery. See also 3.4A
Fuse Rating Fuse Colour Description
1 20 Amps Yellow Motorhome Fridge (where applicable)
2 15 Amps Blue Motorhome Towing (where applicable)
3 7.5 Amps Brown Motorhome Marker Lights (where applicable)
4 15 Amps Blue Motorhome Fridge D+ (where applicable)
5 10 Amps Red Fans
6 10 Amps Red 12V Sockets
7 10 Amps Red Front Internal Lights
8 10 Amps Red Water Pumps
9 15 Amps Blue Electric Step (where applicable)
10 10 Amps Red MotorhomeTankHeaters(whereapplicable)
11 10 Amps Red Auxiliary Supplies (where applicable)
12 5 Amps Tan Electronics
13 5 Amps Tan Ignitions
14 10 Amps Red Rear Internal Lights
15 25 Amps Clear Charger (fuse fitted internally to PSU)
Fuse Rating Fuse Colour Description
Battery 1 20 Amps Yellow Fuse remotely located near battery
Battery 2 20 Amps Yellow Fuse remotely located near battery 2 (where fitted)
3.5 12 Volt DC Fuses
WARNING: When replacing fuses always
replace a fuse with the correct value.
NEVER replace with a higher value /
rating as this could damage the wiring
harness. If a replacement fuse ‘blows’
do not keep replacing the fuse as you
could damage the wiring harness. Please
investigate the fault and contact your
dealer.
The following table shows the fuse allocation
for the 15 fuses fitted to the PSU. Please note
that fuses are dependant on PSU versions, so
not all fuses may be present.
