Axess
®
Pro 1505 Installation Instructions
Technical Specifications Single Phase
Power supply 230Va.c. 50Hz
Motor type Single Phase 240 Volts (Delta Connection)
Model
Motor Power
AX1505
0.373 KW
Track
Maximum Door Opening
Maximum Door Size / Area
4m Track
3.6m
25m
2
6m Track
5.6m
25m
2
Duty Cycle 60%
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity 511 X 4 button Transmitter Codes
Receiver Sensitivity – 103 dB
Transmitter frequency UHF Multi-frequency FM Transmitter
Coding type Code hopping
Number of code combinations Over 100 billion random codes
Code generation Non-linear encryption algorithm
Controller fuse 10A slow blow
Transmitter Battery CR - 2032 (3 Volts)
Real Time Clock Battery CR -1220 (1.5 Volts)
NOTE:
a. If the Safety Beams are not installed then the controller will automatically go into “Safety Close“ mode. A limited
number of features are available in this mode, please refer to menu 6.1 in Section 13.1.
18. Specifications
17. Accessories Installation
17.1 Fitting Courtesy Lights
A light relay module (optional) can be connected to the aux out on the console to control the courtesy light.
WARNING: A qualified electrician must perform the installation where 240V AC power is used.
Menu 4. Light Times
a. Press NEXT or PREV on the wall control unit to navigate to Menu 4 Light/Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the sub menu.
d. Press OPEN to increase or CLOSE to decrease the time.
e. Press SET to save the new time.
f. Press the STOP button two times to exit.
g. Test the light operation.
To Next Page
