Automatic Technology Axess Pro 1505 - 4 Kit Contents

Installation Instructions Axess
®
Pro 1505 7
4. Kit Contents
Fig 4.1
1
2
3
4
5
6
7
8
9
10
11
12
ITEM DESCRIPTION QTY ORDER
CODE
1 AXESS 1505 V1 POWER DRIVE PACK 1 18105
2 LOGIC CONSOLE V2 1 61565
3 PTX-5V2 TC-128 TRANSMITTERS 2 61167
4 SAFETY BEAMS WITH WIRES AND BRACKETS 1 61904
5 BENT ARM 1 62800
6 STRAIGHT ARM 1 62790
ACCESSORY PACK
7 NILOCK NUT M8 1 10860
8 WALL BRACKET 1 62525
9 HEX HEAD SCREW M8 X 70 1 10088
10 SLEEVE 081246 1 64385
11 DOOR BRACKET LOCATOR 1 62515
12 DOOR BRACKET 1 62511
13 PIN SNAP SSP 8 ZNU 31080 2 10720
14 HEX HEAD SCREW M8 X 25 2 10110
15 CLEVIS PIN 0829 2 62551
16 HEX SERRATION FLANGE NUT M8 2 10148
17 SPACE HEAD CAP SCREW M5 X 45 2 10008
18 SPACE HEAD CAP SCREW M6 X 12 2 10010
RAIL
22 4M RAIL 1 92509
13
14
15
16
17
18
22
