Automation Technology C2 Series User Manual

8

C2 Series User Manual Rev. 1.9
C2-2040(HS)-GigE
Parameters
Specifications
Sensitivity
16000 LSB / µJ / cm
2
@ 550 nm
Maximum Spectral Response
0.290 A / (W nm) @ 665 nm
Resolution
2048 x 1088 pixels
Pixel Size
5.5 µm x 5.5 µm
Sensor Size
11.264 mm x 5.984 mm, diagonal: 12.75 mm
Sensor Format
2/3”
Sensor ADC Resolution
10 bit
Sensor Dynamic Range
90 dB with HDR
Max. Internal Full-Frame Rate for
Image Mode
340 fps
Max. External Full-Frame Rate
for Image Mode
(limited due to GigE bandwidth)
50 fps
Effective Frame / Profile Rate at
Max. Row Length
Number of
Rows
Effective Frame / Profile Rate (Hz)*
C2-2040HS-GigE
C2-2040-GigE
8
16
32
64
128
256
512
1088
25000
16000
9540
5240
2700
1400
723
340
1400
1400
1400
1400
1400
1400
723
340
*with Frame Overhead Time (FOT) = 3
