Index Definition
Index #
Range
Description
Profile_idx
1-16384
Index of Profile
AOI_idx
1-8
Index of sensor AOI
NDR_idx
1-4
Index of NDR frame
Examples of Output Frame Structure
1) Configuration with single AOI, single DC, disabled NDR mode and output of 6 profiles resulting to
a frame height of 6 rows:
ProfilesPerFrame = 6
NumAOIs = 1
EnableDC0 = false
EnableDC1 = false
EnableDC2 = true
NDRMode = ”Off”
Row #
Description
Profile #
1
Data of DC2 readout from AOI1
1
2
Data of DC2 readout from AOI1
2
3
Data of DC2 readout from AOI1
3
4
Data of DC2 readout from AOI1
4
5
Data of DC2 readout from AOI1
5
6
Data of DC2 readout from AOI1
6
