Automation Technology C2 Series User Manual

C2 Series User Manual Rev. 1.9

7
The Sensor Specifications
C2-640-GigE
Parameters
Specifications
Sensitivity
17000 LSB / µJ / cm
2
@ 630 nm
Maximum Spectral Response
0.37 A / (W nm) @ 665 nm
Resolution
648 x 488 pixels
Pixel Size
7.4 µm x 7.4 µm
Sensor Size
4.795 mm x 3.611 mm, diagonal: 6 mm
Sensor Format
1/3”
Sensor ADC Resolution
10 bit
Sensor Dynamic Range
90 dB with HDR
Max. Internal Full-Frame Rate
for Image Mode
520 fps
Max. External Full-Frame Rate
for Image Mode
(limited due to GigE bandwidth)
320 fps
Effective Frame / Profile Rate at
Max. Row Length
Number of Rows
Effective Frame / Profile Rate (Hz)
8
16
32
64
128
256
488
15083
10256
6254
3512
1872
968
516
