C2 Series User Manual Rev. 1.9
Trigger Control – RS422 Resolver
The TriggerCoord node always counts all the raw trigger signals arriving at the camera
-> rising AND falling edge!
The TriggerDivider is used internally by the camera. The camera doesn’t change its behavior if the
TriggerDivider is set to another value. A TriggerDivider of 10 for example will use every tenth incoming
trigger for one profile measurement.
If single-ended encoder signals are required it is set over TriggerSingleChannelMode. Triggering over
Channel A or B or over Input1 and Input2 is then possible.
If other encoder signals than RS422 are needed, use the Inputs of the camera instead of the encoder
inputs and set UseAlternateResolverInputs to true.
Trigger divider
Min: 1
Max: 65535
Increment: 1
Count resolver pulses in
both directions
Reverse the resolver count
direction
TriggerSingleChannelMode
(*)
Enable resolver in single
channel mode
(1): Disabled (Value= 0)
(2): EnableIn1 (Value= 1)
(3): EnableIn2 (Value= 2)
TriggerDividerLoadAtStart
(*)
Load trigger divider upon
start trigger
Reset the Trigger
Coordinate/Counter at
Zero Position (Index, Z-
Channel)
(1): Off (Value= 0)
(2): On (Value= 1)
TriggerCoordinateCountAlways
TRUE: Count trigger
coordinate always, FALSE:
Count trigger coordinate
