Automation Technology C2 Series User Manual

C2 Series User Manual Rev. 1.9

33
3) Configuration with single AOI, single DC, NDR mode with two NDR frames and output of 3 profiles
resulting to a frame height of 6 rows:
ProfilesPerFrame = 3
NumAOIs = 1
EnableDC0 = false
EnableDC1 = false
EnableDC2 = true
NDRMode = ”On”
NumberOfNDRFrames = 2
Row #
Description
Profile #
1
Data of DC2 extracted from NDR1, readout from AOI1
1
2
Data of DC2 extracted from NDR2, readout from AOI1
3
Data of DC2 extracted from NDR1, readout from AOI1
2
4
Data of DC2 extracted from NDR2, readout from AOI1
5
Data of DC2 extracted from NDR1, readout from AOI1
3
6
Data of DC2 extracted from NDR2, readout from AOI1
