C2 Series User Manual Rev. 1.9

 In addition when using Single-Ended Encoders of HTL type the jumpers HTLs_A, HTLs_B and

HTLs_Z must be set.

 The isolated digital outputs of C2-I/O Panel can be operated either with TTL level or with

higher voltage (9–24V DC). In the latter case an external voltage supply must be connected

Track A

Track B

Track Z

n.c.

Differential

Single-Ended

HTLs_A

HTLs_B

HTLs_Z

Default Chapter3
