Autonics CT6Y-2P series - When PRESET 1 Is Larger or Equal than PRESET 2 at at down Mode

7 Counter Mode
© Copyright Reserved Autonics Co., Ltd. 53
7.5.3 When PRESET 1 is larger or equal than PRESET 2 at at down
mode
(1) PRESET1 > PRESET2
 Output of OUT1 does not execute.
(2) PRESET1=PRESET2
 Output of OUT1 turns ON for RESET OFF.
