Autonics TM4 Series User Manual For Communication

1 Modbus RTU Protocol
14 © Copyright Reserved Autonics Co., Ltd.
1.4 Read input registers(Func 04–04H)
Read the Binary data of Input Registers(3X reference) in Slave device.
(1) Query (Master)
Slave
address
Function
Starting address
No. of points
Error check(CRC16)
High
Low
High
Low
Low
High
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
1Byte
(2) Response (Slave)
Slave
address
Function Byte count Data Data Data
Error check(CRC16)
Low
High
1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte 1Byte
If read the 2 values within the range from Input Register 300001(0000 H) to 300002(0001 H) on
Slave(Address 17) from Master.
 Query (Master)
Slave
address
Function
Starting address
No. of points
Error check(CRC16)
High
Low
High
Low
Low
High
11 H 04 H 00 H 00 H 00 H 02 H ## H ## H
If the values of 300001(0000 H) and 300002(0001 H) on Slave are respectively “10(A H)” and
“20(14 H)”.
 Response (Slave)
Slave
address
Function Byte count
Data
Data
Error check(CRC16)
High
Low
High
Low
Low
High
11 H 04 H 04 H 00 H 0A H 00 H 14 H ## H ## H
CRC16
CRC16
