Autonics TM4 Series User Manual For Communication

2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 31
2.5.7 Alarm setting group (Func: 03/06/16, RW: R/W)
No(Address)
Parameter Description Setting range Unit
Factory
default
TM2
TM4
400501(01F4) -
Alarm1
Target Ch
Alarm output 1
target Ch
0: CH1 1: CH2
2: CH1 or CH2 3: CH1 and CH2
- 0
400502(01F5) -
Alarm1
Mode
Alarm output1
operation mode
0: OFF 1: AL-1 2: AL-2
3: AL-3 4: AL-4 5: AL-5
6: AL-6 7: LBA 8: SBA
9: HBA
- 1
400503(01F6) -
Alarm1
Type
Alarm output 1
option
0 : AL-A 1 : AL-B 2 : AL-C
3 : AL-D 4 : AL-E 5 : AL-F
- 0
400504(01F7) -
Alarm1
Low_Ch1
Alarm output 1
Ch1low-limit value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400505(01F8) -
Alarm1
High_Ch1
Alarm output 1
Ch1 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400506(01F9) -
Alarm1
Low_Ch2
Alarm output 1
Ch2 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400507(01FA) -
Alarm1
High_Ch2
Alarm output 1
Ch2 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400508(01FB) -
Alarm1
Hysteresis
Ch1
Alarm output 1
Ch1 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400509(01FC) -
Alarm1
Hysteresis
Ch2
Alarm output 1
Ch2 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400510(01FD) -
Alarm1
NO/NC
Alarm output 1
contact type
0: NO 1: NC - 0
400511(01FE) -
Alarm1 ON
Delay Time
Alarm output 1
ON delay time
0 to 3600 Sec. 0
400512(01FF) -
Alarm1
OFF Delay
Time
Alarm output 1
OFF delay time
0 to 3600 Sec. 0
400513(0200) -
LBA1 Time
Ch1
LBA1Ch1
monitoring time
0 to 9999 Sec.
0
400514(0201) - Reserved
400515(0202) -
LBA1 Band
Ch1
LBA1 Ch 1
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400516(0203) -
LBA1 Time
Ch2
LBA1 Ch 2
monitoring time
0 to 9999 Sec. 0
400517(0204) - Reserved
400518(0205) -
LBA1 Band
Ch2
LBA1 Ch2
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400519(0206) -
Alarm2
Target Ch
Alarm output 2
target Ch
0: CH1 1: CH2
2: CH1 or CH2
4: CH1 and CH2
- 1
