Autonics TM4 Series User Manual For Communication

2 Modbus Mapping Table
32 © Copyright Reserved Autonics Co., Ltd.
No(Address)
Parameter Description Setting range Unit
Factory
default
TM2
TM4
400520(0207) -
Alarm2
Mode
Alarm output 2
operation mode
0: OFF 1: AL-1 2: AL-2
3: AL-3 4: AL-4 5: AL-5
6: AL-6 7: LBA 8: SBA
9: HBA
2
400521(0208) -
Alarm2
Type
Alarm output 2
option
0 : AL-A 1 : AL-B 2 : AL-C
3 : AL-D 4 : AL-E 5 : AL-F
- 1
400522(0209) -
Alarm2
Low_Ch1
Alarm output 2
Ch1 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400523(020A) -
Alarm2
High_Ch1
Alarm output 2
Ch1 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400524(020B) -
Alarm2
Low_Ch2
Alarm output 2
Ch2 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400525(020C) -
Alarm2
High_Ch2
Alarm output 2
Ch2 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400526(020D) -
Alarm2
Hysteresis
Ch1
Alarm output 2
Ch1 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400527(020E) -
Alarm2
Hysteresis
Ch2
Alarm output 2
Ch2 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400528(020F) -
Alarm2
NO/NC
Alarm output 2
contact type
0: NO 1 : NC - 0
400529(0210) -
Alarm2 ON
Delay Time
Alarm output 2
ON delay time
0 to 3600 Sec. 0
400530(0211) -
Alarm2
OFF Delay
Time
Alarm output 2
OFF delay time
0 to 3600 Sec. 0
400531(0212) -
LBA2 Time
Ch1
LBA2 Ch1
monitoring time
0 to 9999 Sec. 0
400532(0213) - Reserved
400533(0214) -
LBA2 Band
Ch1
LBA2 Ch1
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400534(0215) -
LBA2 Time
Ch2
LBA2 Ch2
monitoring time
0 to 9999 Sec. 0
400535(0216) - Reserved
400536(0217) -
LBA2 Band
Ch2
LBA2 Ch2
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400537(0218) -
Alarm3
Target Ch
Alarm output 3
target Ch
0: CH1 1: CH2
2: CH1 or CH2
4: CH1 and CH2
- 0
400358(0219) -
Alarm3
Mode
Alarm output 3
operation mode
0: OFF 1: AL-1 2: AL-2
3: AL-3 4: AL-4 5: AL-5
6: AL-6 7: LBA 8: SBA
9: HBA
- 1
