Autonics TM4 Series User Manual For Communication

2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 33
No(Address)
Parameter Description Setting range Unit
Factory
default
TM2
TM4
400539(021A) -
Alarm3
Type
Alarm output 3
option
0 : AL-A 1 : AL-B 2 : AL-C
3 : AL-D 4 : AL-E 5 : AL-F
- 0
400540(021B) -
Alarm3
Low_Ch1
Alarm output 3
Ch1 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400541(021C) -
Alarm3
High_Ch1
Alarm output 3
Ch1 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400542(021D) -
Alarm3
Low_Ch2
Alarm output 3
Ch2 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400543(021E) -
Alarm3
High_Ch2
Alarm output 3
Ch2 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400544(021F) -
Alarm3
Hysteresis
Ch1
Alarm output 3
Ch1hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400545(0220) -
Alarm3
Hysteresis
Ch2
Alarm output 3
Ch2 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400546(0221) -
Alarm3
NO/NC
Alarm output 3
contact type
0: NO 1: NC - 0
400547(0222) -
Alarm3 ON
Delay Time
Alarm output 3
ON delay time
0 to 3600 Sec. 0
400548(0223) -
Alarm3
OFF Delay
Time
Alarm output 3
OFF delay time
0 to 3600 Sec. 0
400549(0224) -
LBA3 Time
Ch1
LBA3 Ch1
monitoring time
0 to 9999 Sec. 0
400550(0225) - Reserved
400551(0226) -
LBA3 Band
Ch1
LBA3 Ch1
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400552(0227) -
LBA3 Time
Ch2
LBA3 Ch2
monitoring time
0 to 9999 Sec. 0
400553(0228) - Reserved
400554(0229) -
LBA3 Band
Ch2
LBA3 Ch2
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400555(022A) -
Alarm4
Target Ch
Alarm output 4
target Ch
0: CH1 1: CH2
2: CH1 or CH2
4: CH1 and CH2
- 1
400556(022B) -
Alarm4
Mode
Alarm output 4
operation mode
0: OFF 1: AL-1 2: AL-2
3: AL-3 4: AL-4 5: AL-5
6: AL-6 7: LBA 8: SBA
9: HBA
- 2
400557(022C) -
Alarm4
Type
Alarm output 4
option
0 : AL-A 1 : AL-B 2 : AL-C
3 : AL-D 4 : AL-E 5 : AL-F
- 0
400558(022D) -
Alarm4
Low_Ch1
Alarm output 4
Ch1 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
