2 Modbus Mapping Table
34 © Copyright Reserved Autonics Co., Ltd.
No(Address)
Parameter Description Setting range Unit
Factory
default
TM2
TM4
400559(022E) -
Alarm4
High_Ch1
Alarm output 4
Ch1 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400560(022F) -
Alarm4
Low_Ch2
Alarm output 4
Ch2 low-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
/A
1550
400561(0230) -
Alarm4
High_Ch2
Alarm output 4
Ch2 high-limit
value
Deviation alarm: -F.S to F.S
Absolute value alarm: Within the
temperature range of input type
℃/℉
1550
400562(0231) -
Alarm4
Hysteresis
Ch1
Alarm output 4
Ch1 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400563(0232) -
Alarm4
Hysteresis
Ch2
Alarm output 4
Ch2 hysteresis
1 to 100 (H)
0.1 to 100.0 (L)
Digit 1
400564(0233) -
Alarm4
NO/NC
Alarm output 4
contact type
0: NO 1: NC - 0
400565(0234) -
Alarm4 ON
Delay Time
Alarm output 4 ON
delay time
0 to 3600 Sec. 0
400566(0235) -
Alarm4
OFF Delay
Time
Alarm output 4
OFF delay time
0 to 3600 Sec. 0
400567(0236) -
LBA4 Time
Ch1
LBA4 Ch1
monitoring time
0 to 9999 Sec. 0
400568(0237) - Reserved
400569(0238) -
LBA4 Band
Ch1
LBA4 Ch1
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
400570(0239) -
LBA4 Time
Ch2
LBA4 Ch2
monitoring time
0 to 9999 Sec. 0
400571(023A) - Reserved
400572(023B) -
LBA4 Band
Ch2
LBA4 Ch2
detection band
0 to 999 (H)
0.0 to 999.9 (L)
℃/℉
3
