Autonics TM4 Series User Manual For Communication

2 Modbus Mapping Table
22 © Copyright Reserved Autonics Co., Ltd.
2.4 Read input register (Func: 04, RW: R)
No(Address)
Parameter
Description
Setting range
Unit
Factory
default
TM2
TM4
3
01001(03E8)
3
01001(03E8)
CH1 Present
Value
Present value
Input range by
sensor type
31000: OPEN
30000: HHHH
-
30000: LLLL
℃
/℉
-
3
01002(03E9)
3
01002(03E9)
CH1 Dot
Sensor decimal point
0: 0
1: 0.0
-
0
3
01003(03EA)
3
01003(03EA)
CH1 Unit
Sensor temperature unit
0:
℃
1:
℉
-
0
3
01004(03EB)
3
01004(03EB)
CH1 Set Value
Temperature setting value
controlled currently
SV
low limit to
SV
high limit
℃
/℉
0
3
01005(03EC)
3
01005(03EC)
CH1
Heating_MV
Heating MV
0.0
to 100.0
%
-
3
01006(03ED)
3
01006(03ED)
CH1
Cooling_MV
Cooling MV
0.0
to 100.0
%
-
3
01007(03EE)
to
3
01012(03F3)
3
01007(03EE)
to
3
01012(03F3)
CH2 Parameter
- the same as above CH1
-
301013(03F4)
to
3
01018(03F9)
CH3 Parameter
- the same as above CH1
-
3
01019(03FA)
to
3
01024(03FF)
CH4 Parameter
- the same as above CH1
3
01025(0400)
-
-
CH1 LED(OUT)
0: OFF 1: ON
-
-
-
CH2 LED(OUT)
0: OFF 1: ON
-
-
-
-
Fixed as 0
-
-
-
-
Fixed as 0
-
-
-
AL1 LED
0: OFF 1: ON
-
-
-
AL2 LED
0: OFF 1: ON
-
-
-
AL3 LED
0: OFF 1: ON
-
-
-
AL4 LED
0: OFF
1: ON
-
-
-
DI-1 input
0: OFF 1: ON
-
-
-
DI-2 input
0: OFF 1: ON
-
-
-
3
01025(0400)
CH1 LED(OUT)
0: OFF 1: ON
-
-
-
CH2 LED(OUT)
0: OFF 1: ON
-
-
-
CH3 LED(OUT)
0: OFF 1: ON
-
-
-
CH4 LED(OUT)
0: OFF 1: ON
-
-
-
-
Fixed as 0
-
-
-
-
Fixed as 0
-
-
-
-
Fixed as 0
-
-
-
-
Fixed as 0
-
-
-
-
Fixed as 0
-
-
-
-
Fixed as 0
-
-
3
01026(0401)
3
01026(0401)
Unit Address
Unit address
01
to 31
-
01
